SEW wire rope hoists are advanced lifting solutions designed for industrial material handling where reliability, precision, and safety are critical.
They are widely used in steel plants, heavy engineering industries, warehouses, construction, and manufacturing units.
SEW wire rope hoists are adaptable to various crane systems and deliver smooth lifting, reduced downtime, and maximum operator safety.
Whether for steel plants, construction projects, heavy engineering workshops, or warehouses, SEW hoists provide a seamless blend of power and efficiency.
Technical Specifications
| Specification | 1T | 2T | 3T | 5T | 7.5T | 10T |
|---|---|---|---|---|---|---|
| Capacity | 1T | 2T | 3T | 5T | 7.5T | 10T |
| No. of fall | 4 | 4 | 4 | 4 | 4 | 4 |
| Std. lift (m) | 6 | 6 | 6 | 6 | 6 | 6 |
| Wire rope dia (mm) | 6 | 8 | 10 | 12 | 14 | 16 |
| Hoist speed (m/min) | 4 | 4 | 4 | 4 | 4 | 4 |
| Hoist HP | 1 | 2 | 3 | 5 | 7.5 | 10 |
| Cross travel speed (m/min) | 16 | 16 | 16 | 16 | 16 | 16 |
| Cross travel HP | 0.25 | 0.5 | 0.5 | 1 | 1 | 1.5 |
Specifications may vary based on application and customer requirements. Contact us for custom capacity and lift options.
